Cranoglanis bouderius, Helmet Catfish
Dr. John Lundberg - The Academy of Natural Sciences, Philadelphia
Catfish Bones: The Digital Atlas of Catfish Morphology
Cranoglanis bouderius
Click for help
skull
Click for more information

The Academy of Natural Sciences of Philadelphia (ANSP 164978)

Image processing: Dr. Jennifer Olori
Publication Date: 04 Jan 2007

ITIS TNS Google MSN

The imagery on this page is the basis for a paper entitled CAT scan-based images of the skeleton of the Asian catfish Cranoglanis (Siluriformes: Cranoglanididae) by K.R. Luckenbill and J.G. Lundberg (Proceedings of the Academy of Natural Sciences of Philadelphia, 158, 297-299). The Abstract is as follows:

Figured on the following two pages are 3D models of the bony skeleton of the Asian catfish Cranoglanis bouderius, produced with High Resolution X-ray Computed Tomography (HRXCT) imaging methods. The scanned specimen is from China, Guangdong Province Guangzhou city, and is deposited at the Academy of Natrual Sciences: ANSP 164978, Standard Length = 125 mm. Additional images and animations of this specimen are publicly available at the CatfishBones website, http://catfishbone.acnatsci.org/.

About the Species

This specimen was collected from Canton, China. It was made available to The University of Texas High-Resolution X-ray CT Facility for scanning by Dr. John Lundberg of the Academy of Natural Sciences, Philadelphia. Funding for scanning was provided by a National Science Foundation grant (DEB-0089612) to Dr. Lundberg. Funding for image processing was provided by an NSF Digital Libraries Initiative grant to Dr. Timothy Rowe of The University of Texas at Austin.

Dorsal view

Lateral view

About this Specimen

This specimen was scanned by Matthew Colbert on 8 October 2004 along the coronal axis for a total of 645 slices. Each 1024x1024 pixel slice is 0.0877 mm thick, with an interslice spacing of 0.0877 mm and a field of reconstruction of 40 mm.

About the
Scan

Links

Cranoglanis bouderius page on the Catfish Bones website

pictures of C. bouderius on PlanetCatfish.com

Literature
& Links

None available.

Additional
Imagery

To cite this page: Dr. John Lundberg, Catfish Bones: The Digital Atlas of Catfish Morphology, 2007, "Cranoglanis bouderius" (On-line), Digital Morphology. Accessed October 31, 2014 at http://digimorph.org/specimens/Cranoglanis_bouderius/.
